 MP4/ mp3 Players |
|
|
||||
| System Requirements |
| Hardware | IBM PC or compatible PC, Notebook or Macintosh with USB port |
| Operation System | Windows98/98SE/Me/2000/XP and Linux2.4/Mac OS9.0 above |
| Driver installation | Only required for Windows98/SE |
| Function characteristics |
| USB Interface | USB2.0 high speed |
| Capacity | 1GB, 2GB，4GB(Optional) |
| Storage Device | Removable Storage Device |
| Card type | N/A |
| A-B Repeat | Available |
| Recording | Support Microphone Recording |
| EQ Mode | Normal， Pop， Rock，Classical，Jazz，Bass |
| Supported Language | 15 languages support（Optional） |
| Play Mode | Normal, Repeat all, Repeat one, repeat Folder，Folder，Random，Intro |
| FM Radio | Available |
| VBR | Available |
| Technical Specification |
| Read speed | MLC：5.0~6.4MB/S ；SLC：8~9.0MB/S | |
| Write speed | MLC：2~2.5MB/S ；SLC：5~5.5MB/S | |
| Audio format | MP3，WMA | |
| Bit Rate | 8Kbps—320Kbps | |
| Recording Length | WAV：About 3 hours（88Kbps/22KHz）/128M，About 4 hours (64Kbps/16KHz)/128M, About 6 hours(44Kbps/11KHz)/128M,About 8 hours (32Kbps/8KHz)/128M | |
| Battery Life | About 10-20 Hours | |
| LCD Display | 132*32 (single color) | |
| SNR | ≥90dB | |
| Frequency Response Range | 20Hz—20KHz(Only MP3/WMA) | |
| FM transmitting mode | Manual selection of transmitting channel | |
| FM transmitting frequency range | 88.1MHz—107.9MHz | |
| Transmitting power(direct) | 88.1MHZ | -18 +/- 10 dBm |
| 88.1MHZ | -18 +/- 10 dBm | |
| 107.9MHZ | -18 +/- 10 dBm | |
| Transmitting Modulation deviation (VOL=18) | 88.1MHZ | 65 +/- 15 KHz |
| 88.1MHZ | 65 +/- 15 KHz | |
| 107.9MHZ | 65 +/- 15 KHz | |
| SNR(FM Transmitting) | 88.1MHz—107.9MHz | ≥40dB |
| Transmitting distance | ≥3m | |
| Audio detection | Stop transmitting if no audio signal is detected within 60S | |
| Operation Current(EQ=Normal) | MP3/WMA play mode | 40 +/- 20mA |
| FM Transmitting mode | 90 +/- 20mA | |
| Physical Characteristics |
| Battery Type | 1 * AAA battery (alkaline) |
| Storage Temperature | -20℃ ~ +55℃ |
| Ambient Temp* | -10℃ ~ +55℃ |
| Operation Relative Humidity* | 20% ~ 90%（40℃）） |
| Storage Relative Humidity* | 20% ~ 93%（40℃） |
| Size（mm） | L*W*H :84*29*19（mm） |
| Weight（g） | About 31g |
| Color | black |
| Package | Blister package, color box |
| EMI Compliance | CE |
 |
